Shenhui Laser CO2 460 60W laser engraving cutting machine price
-
10 - 19 Sets
$1,650.00
-
>=20 Sets
$1,450.00
- Power(W):
- 60w
- Model Number:
- SH-G460 laser engraving machine
- Lead Time:
-
Quantity(Sets) 1 - 5 >5 Est. Time(days) 5 Negotiable
- After-sales Service Provided:
-
Video technical support, Engineers available to service machinery overseas
- Applicable Material:
-
Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood
- Laser Type:
-
CO2
- Engraving Speed:
-
0-60000mm/min
- Graphic Format Supported:
-
AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
- Application:
-
Laser Engraving
- Applicable Industries:
-
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
- Engraving Area:
-
600*400mm
- Condition:
-
Used
- CNC or Not:
-
Yes
- Cooling Mode:
-
Water Cooling
- Place of Origin:
-
Shandong, China
- Brand Name:
-
SHENHUI
- Dimension(L*W*H):
-
1020*700*600mm
- Certification:
-
CCC, CE, GS, ISO, SGS, UL
- Warranty:
-
1 Year
- Laser Source Brand:
-
Lianpin
- Key Selling Points:
-
Competitive Price
- Name:
-
Mini Laser Engraving Machine
- Laser tube:
-
Sealed CO2 Glass Tube
- Model:
-
640
- Product name:
-
Laser Engraving Equipment
- Function:
-
Cutting Engraving Marking
- Keywords:
-
60w Wood Laser Engraving Machine
- Software:
-
Lasercut
- Type:
-
Water Cooling CO2 Laser Engraving Machines
- Supply Ability:
- 300 Set/Sets per Month Advertise cnc laser 6040 cutting engraving machine
- Packaging Details
- laser engraving machine packing
wood packing size
150x 90x x 87cm
150kgs
- Port
- qingdao,shanghai,ningbo
- Picture Example:
-
- Lead Time :
-
Quantity(Sets) 1 - 5 >5 Est. Time(days) 5 To be negotiated
Advertise cnc laser 6040 cutting engraving machine
Applicable Materials
wood, bamboo, jade, marble, organic glass, crystal, plastic, fabric, paper, leather, cermic, glass and other non-metal.
Applicable Industry
Advertisement, arts and crafts, toys, garments, model, building upholster, cumputerized embroidery and clipping, packing and paper industry.
Parameter List
Laser Power | 60W/100W(optional) |
Laser Type | Hermetic CO2 glass tube |
Power Supply | AC220±10% /AC110±10% |
Working Area | 600X400mm |
Max Moving Speed | 0-40000m/min |
Locating Precision | <0.01 mm |
Min Shaping Character | Character:3x3mm,letter:2x2mm |
Resolution Ratio | ≤4500 dpi |
Control Configuration | DSP |
Data Transfer Interface | USB (offline);Internet;Wifi |
Operating Temperature | 0°C-45°C |
Worktable | Honeycomb/ Automatic up&down worktable |
System Environment | WINDOWS 2000/ XP/ Vista/ Win7/ Win8 |
Cooling Way | Water cooling |
Software | LaserworkV8.0 /Lasercut6.0 |
Compatible Software | CoreIDraw,AutoCAD |
Cutting Thickness | 0-30mm (Depends on different materials) |
Color Separation | Separation of cutting up to 256 colors |
Sloping Engraving | Yes,slop can be designed discretionarily |
Cuts off the Water Supply the Protection | Yes (water safely switch) |


Two Years Warranty
1) 24 Hours online service.
2) 24 months warranty for the whole machine except for wearing parts.
3) Engineers available to service machinery overseas.
For offer the most suitable machine with favorable price,
would you like to confirm below questions:
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
1) What is your reuqested max working area, X:___mm, Y:___mm?
2) What mainly job you do ? Only engrave, cut or both ?
3) What kind of your materials, metal or non-metal, what are they?
..............................................................................................................
After your return comments, we will send you more information about the machine along price .
FAQ
Frequently Asked Questions
Q:How to chose laser machine equipment?
A: It depends on material max size to choose working table size .e.g, you want to cut max wood size is 600x900,tell us your max size material, we produce for your 600x900 size machine .
Q:What delivery date ?
A: Usually 5-20 working days after payment according to different order machine style and quantity.
Q:How to payment ?
A: Alibaba Trade Assurance by Credit card, Cash in factory, TT,LC,DP ,West union ,Paypal etc.
Q: Do you supply overseas service ?
A: Yes, we do . We have strong after sales service team 10 engineers with different languages.
Q: How to Warranty time ?
A: Usually two years for the machine .3-12 months for laser tubes and lens.
Q: Can we use our own brand on our machine ?
A: Yes, of course , we supply OEM .
Q: How about service after sales ?
A: we supply 24 hours online service , and whole life technical server support any time.
Q: How man years of your laser company ?
A: Since 1993 in laser fields , more than .20 years ,since 1997 named Shenhui laser Equipment company Leading manufacturer on laser CNC machines .
Company profile
1 | Shenhui laser e-catalogue | https://youtu.be/ZIaCfe5b4a4 |
2 | Shenhui laser Company vedio | https://youtu.be/TMlntENPjKQ |
3 | Shenhui Working Office vedio | https://youtu.be/fUqJBsNTROc |
Why SHENHUI Laser equipment
SHENHUI laser, as a professional provider of laser system since 2003,In 1997 named SHENHUI LASER EQUIPMENT CO LIMITED by embracing the latest technology, is continuing to develop faster, higher quality, longer lasting laser systems that can better meet your needs.
If you want to know why you should choose a SHENHUI laser system, there are so many reasons.... we can supply best Laser Machine solution for your work and suggestions for your distribute market . ( CO2 Laser ,CNC router,Fiber laser,CNC laser,Laser tube ....) we have good management team ,company development better and better ....
You can merely find a laser system with such a reliable tech support, extensive user manuals, technical guiding videos, great feedbacks from customers, unique accessories (HR head, rotary axis,CO2 glass tubes,German design casebody), and reasonable price. Our customers come from every country in the word and we keep good relations, if you like, most of them are willing to show you the machine.
CE marker cables and Germany spare parts
Trade Assurance Order -Give us one order garranty your machine
Two Years Warranty
(not include electronic parts and tubes etc)
1) 24 Hours online service.
2) 24 months warranty for the whole machine except for wearing parts.
3) Engineers available to service machinery overseas.
For offer the most suitable machine with favorable price,
would you like to confirm below questions:
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
1) What is your reuqested max working area, X:___mm, Y:___mm?
2) What mainly job you do ? Only engrave, cut or both ?
3) What kind of your materials, metal or non-metal, what are they?
..............................................................................................................
After your return comments, we will send you more information about the machine along price .
And below is Parameter to cut differerent materials by laser engraving machine for your reference .
FAQ
Frequently Asked Questions
Q:How to chose laser machine equipment?
A: It depends on material max size to choose working table size .e.g, you want to cut max wood size is 600x900,tell us your max size material, we produce for your 600x900 size machine .
Q:What delivery date ?
A: Usually 5-20 working days after payment according to different order machine style and quantity.
Q:How to payment ?
A: Alibaba Trade Assurance by Credit card, Cash in factory, TT,LC,DP ,West union ,Paypal etc.
Q: Do you supply overseas service ?
A: Yes, we do . We have strong after sales service team 10 engineers with different languages.
Q: How to Warranty time ?
A: Usually two years for the machine .3-12 months for laser tubes and lens.
Q: Can we use our own brand on our machine ?
A: Yes, of course , we supply OEM .
Q: How about service after sales ?
A: we supply 24 hours online service , and whole life technical server support any time.
Q: How man years of your laser company ?
A: Since 1993 in laser fields , more than .20 years ,since 1997 named Shenhui laser Equipment company Leading manufacturer on laser CNC machines .
Our shenhui laser laser machines export each model and a lots of products will be tested stricktly .
We also looking for good sales agent or trader in different country ,welcome you inquiry us.
Warranty:
1.Machine machinery parts is 2 years under normally operating machine according to users manual.
(not include damagable spare parts and electronic spare parts).
2.Laser lens and mirrors warranty is 3 months;
3.Laser tube reci warranty is 10 Months according to www.recilaser.com manufacturer.
(10000 working hours)
4.Laser tube EFR warranty is 10 Months and 12 Months according to www.bjefr.com manufacturer.
(F series and ZS series) 8000 working hours and 10000 working hours life span .
5.Electronic spare parts ( motors and motherboard and laser power supply ) warranty is 12 Months.
6. Damagable spare parts for laser engraving machines ( water pumps, water protective , red dot system , lens limit...,
will be sent to you free charge with machine )
Maintains:
1.During warranty, we can supply you spare parts freely .
2.We supply you technical support whole life on laser machine.
3.24 hours online after sales service from Technical engineers.
4.Enginners go to abroad to give technical service .
Laser tubes for CO2 laser engraving and cutting machines of EFR parameters photo.
Laser tubes for CO2 laser engraving and cutting machines of EFR parameters photo.
www.bjefr.com
CO2 different power cut thickness on different materials
Materials | 40W | 50W | 60W | 80W | 100W | 150W | 200W | 360W |
Wood | 3mm | 4mm | 5mm | 10mm | 12mm | 15mm | 18mm | 20mm |
Plywood | \ | 4mm | 5mm | 10mm | 12mm | 15mm | 18mm | 20mm |
Glass | \ | \ | \ | \ | \ | \ | \ | \ |
Leather | 1mm | 1.5mm | 2mm | 3mm | 4mm | 5mm | 8mm | 8mm |
Acrylic | 3mm | 8mm | 10mm | 15mm | 20mm | 20mm | 25mm | 30mm |
PVC | 1mm | 2mm | 3mm | 4mm | 5mm | 6mm | 8mm | 10mm |
Plexiglass | 3mm | 5mm | 6mm | 8mm | 10mm | 12mm | 15mm | 20mm |
Plastic | \ | 1.5mm | 2mm | 3mm | 4mm | 5mm | 6mm | 10mm |
Rubber | \ | 2mm | 3mm | 4mm | 5mm | 6mm | 8mm | 10mm |
Crystal | \ | \ | \ | \ | \ | \ | \ | \ |
Jade | \ | \ | \ | \ | \ | \ | \ | \ |
Stone | \ | \ | \ | \ | \ | \ | \ | \ |
Polymethyl Methacrylate Plastics | \ | 8mm | 10mm | 15mm | 20mm | 20mm | 25mm | 30mm |
Marble | \ | \ | \ | \ | \ | \ | \ | \ |
medal | \ | \ | \ | \ | \ | \ | 1.5mm | 2mm |
Clothing | 0.5-3mm (fabric/wool) | |||||||
Bamboo Works | \ | 3mm | 3mm | 4mm | 5mm | 6mm | 8mm | 10mm |
Paper | 0.5-3-5mm | |||||||
Above sheet only for reference,because in different country same materials different components |
CO2 laser cut machine engrave cut on different materials
item | Materials | Engrave | Cut |
1 | wood | √ | √ |
2 | Acrylic | Yes | Yes |
3 | Fabric | Yes | Yes |
4 | Glass | Yes | No |
5 | Coated Metals | Yes | No |
6 | Ceramic | Yes | No |
7 | Delrin | Yes | Yes |
8 | Cloth | Yes | Yes |
9 | Leather | Yes | Yes |
10 | Marble | Yes | No |
11 | Matte Board | Yes | Yes |
12 | Melamine | Yes | Yes |
13 | Paper | Yes | Yes |
14 | Mylar | Yes | Yes |
15 | Pressboard | Yes | Yes |
16 | Rubber | Yes | Yes |
17 | Wood Veneer | Yes | Yes |
18 | Fiberglass | Yes | Yes |
19 | Painted Metals | Yes | No |
20 | Tile | Yes | No |
21 | Plastic | Yes | Yes |
22 | Cork | Yes | Yes |
23 | Corian | Yes | Yes |
24 | Anodized Aluminum | Yes | No |
25 | Stainless Steel | yes | yes |
26 | Brass | No | No |
27 | Titanium | No | No |
28 | Bare Metals | No | No |
Laser engraving cutting machine
Working Samples
What Products can you creat ?
Laser engaving cutting MACHINE and fiber marking machineVedios
https://youtu.be/4KQzh1ntRGU | Laser engraving cutting on wooden 150w |
https://youtu.be/vfUbLIza_M0 | Laser engraving cutting on leather 100w |
https://youtu.be/imI7ha9pbkQ | Laser engraving cutting on Acrylic 130w |
https://youtu.be/GEphz7IG0yY | Laser engraving cutting on fabric 80w |
https://youtu.be/B-PqDO4h1hA | Laser engraving on round objects 60w |
https://youtu.be/Pu3GNkZv7Jg | Laser marking on metal PVC seals 20 |
