40w non-metal materials cheap co2 laser engraver SH-K40
- Shipping:
- Support Sea freight
- Applicable Material:
-
Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood
- Laser Type:
-
CO2
- Engraving Speed:
-
0-30000mm/min
- Graphic Format Supported:
-
AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
- Engraving Area:
-
300*200mm
- Condition:
-
New
- CNC or Not:
-
Yes
- Cooling Mode:
-
Water Cooling
- Place of Origin:
-
Shandong, China
- Brand Name:
-
SHENHUI
- Model Number:
-
SH-K40
- Dimension(L*W*H):
-
800*500*250mm
- Certification:
-
CCC, CE, GS, ISO, SGS, UL
- Laser power:
-
40W/50W
- Name:
-
stainless steel engraving machine laser engraving
- Type:
-
Water Cooling CO2 Laser Engraving Machines
- Software:
-
Newlydraw
- Function:
-
Engraving Nonmetal Materials
- worktable:
-
300*200mm
- Model:
-
SH-K40
- Color:
-
blue/black/red white
- Product name:
-
40w laser engraving machine SH-K40
- Keywords:
-
40 Laser Engraving Machine
- After-sales Service Provided:
-
Engineers available to service machinery overseas
- Supply Ability:
- 1000 Set/Sets per Month
- Packaging Details
- standard wooden box
- Port
- qingdao
- Lead Time :
- three working days
Applicable Materials
- It can be used in various non-metal materials such as rubber,acrylic,plexiglass,crystal,wood etc.
Applicable Industry
- Applying for processing of small-size artistic products. For the engraving of patterns and characters of double-color planks,woodboard,bamboo piece,organic glass plank and cloth. The patterns and characters engraved are real to life and pleasing to the eye.
- For the engraving of titles,types,signs,patterns etc.on electronic parts,which will last for long time.
Technical Parameters of The Machine
- Laser Power: 40W
- Power Supply: AC220±10% 50HZ/AC110±10% 60HZ
- Operating Temperature: 5°C-35°C
- Working Area: 200x300mm
- Compatible Software: CoreDraw
- Picture Format: BMP/JPG/JPEG/WMF/EMF/PLT etc
- Working Speed:0-50mm/s
- Package: polywood
- Machine Dimension:800x500x250mm
- Package Dimension: 970x670x400mm
- Net Weight/Gross Weight: 20kg/40kg

Below is suggested parameters for some materials. ( the parameters might be a bit different according to different machines) Our machine can also work on many other non-materials like rubber foam cardboard paper plastic glass rostone...if u want to know their parameters, u can contact me through Wechat/Whatapp/Skype/email.
Materials | Power | Mode | Speed(mm/s) | Output(%) | Interval |
Painted metal matrial | 60w | Scan | 200 | 28-30 | 0.08 |
5mm acrylic
| 40w | Scan | 350 | 15-18 | 0.08 |
40w | Cut | 6 | 85-90 | ||
80w EFR | Scan | 350 | 20-20 | 0.08 | |
80W EFR | Cut | 14 | 85-90 | ||
leather | 40W | Scan | 300 | 11-11 | 0.08 |
40W | Cut | 15 | 35 | ||
80W EFR | Cut | 80 | 25-25 | ||
Denim fabric | 40W | Cut | 50 | 50-50 | |
40W | Scan | 350 | 10-10 | 0.1 | |
80W EFR | Scan | 350 | 16-16 | 0.1 | |
80W EFR | Cut | 70 | 35-35 | ||
3mm plywood | 40W | Cut | 15 | 65-70 | |
40W | Dot | 30 | 9-9 | ||
40W | Scan | 350 | 15-15 | 0.08 |
How Does Laser Cutting Work?
Laser cutters create designs and patterns by cutting into materials. It is subtractive manufacturing technology that the machine use a powerful laser beam source to melt, burn, or vaporize material away. A laser cutter typically follows directions from computer numerical control (CNC).
The process starts with an extremely small laser beam that is emitted from a tube when a current passes through. This current causes the laser to reflect off a partial mirror and point through a focal lens in the machine head. Following the vector file that holds the 2D design, the laser beam cuta away at a materials until the image is completed. These laser cutting machines are highly capable of creating finely detailed patterns with a high-quality surface finish. There is a wide range of laser cutting techniques and compatible materials that you can use.
Laser Cutter Materials
Depending on the type of laser that is utilized, there's a wide range of compatible materials available. With the co2 laser cutter, you can use wood, acrylic, leather, glass, plastics, foams, as well as cardboard and other paper materials.
How to Design for Laser Cutting?
When creating a design or pattern for laser cutting, you can use eigher 2D or 3D softare. Laser cutters essentially function like an average 2D inkjet printer but come with drivers that allow the laser cutting machine follow specific designs. While these specific drivers are highly common in 2D design software, there is less support from 3D software.
Graphic design software like Adobe Illustrator and free drawing tools like AutoCAD are ideal 2D programs for laser cutting technology.
Laser Cutting Techniques
Vector Cutting: With vector cutting, the laser beam is continuously fired, cutting directly through the material. This technique is solely used for vector graphics and extremely small lines.
Raster Engraving: Contrary to vector cutting, the rastering process burns off only the top layer of the materials instead of cutting all the way through it. The design is engraved in a different color, integrating the image within the selected materials. To do this, the laser is usually preset to a lower power level. Instead of a high-powered pulsing beam, the laser cutter unfurls finely detailed dots to produce the design without cutting through the material.
We have certification of CE of laser machine, CE of the motor, CE of the laser tube, FDA of our machine and all kinds of company certificantion.
Liaocheng Shenhui Laser Equipment Co.,Ltd. is a professional large-scale laser equipment R&D manufacturer. Established in 1997, our factory covers an area of 33000 square meters,with 257 employees,including 37 researchers,16 doctors & postgraduates and 3 professors. We have ISO9001 and CE certificates. We also have established long-term and good cooperative relationships with Beijing University of Technology,Shangdong Laser Graduate School,Shangdong University Graduate School and Hebei Light Graduate School.
With high-grade assembly line,advanced checking instruments and precise laboratory,as well as experienced technicians,talented R&D and management employees,our company is proud of our high quality equipment and research ability. The Products of our company strictly abibe by professional design techniques,so that our products have excellent performance with precision and nice appearance.
