Cheap price jewelry silver gold 20w fiber laser engraving marking machine for sale

  • >=1 Sets
    $2,790.00
Power(W):
20W
Model Number:
SH-F20
Lead Time:
Quantity(Sets) 1 - 10 11 - 20 >20
Est. Time(days) 7 15 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
After-sales Service Provided:
Online support, Engineers available to service machinery overseas
Applicable Material:
Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood, Cooper silver hard alloy
Laser Type:
Fiber Laser
Engraving Speed:
7000mm/s
Graphic Format Supported:
AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Application:
Laser Engraving
Engraving Area:
110*110mm 200*200mm 300*300mm
Condition:
New
CNC or Not:
Yes
Cooling Mode:
Air Cooling
Place of Origin:
Shandong, China
Brand Name:
Shenhui
Dimension(L*W*H):
840*400*740mm
Certification:
CE, ISO, SGS, FDA
Warranty:
1 Year
Laser Source Brand:
MAX
Key Selling Points:
Automatic
Product name:
Fiber Laser Marking Machine
Laser power:
10W 20W 30W 50W(optional)
Cooling system:
Air Cooling System
Laser source brand:
Max/Raycus
Marking line width:
0.01-0.1mm
Software:
Ezcad(in English)
Working voltage:
AC110V/220V
Min letter:
0.15mm
Repeatable Accuracy:
0.001mm
Supply Ability
Supply Ability:
1000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Plywood case for laser marking machine
Port
Qingdao/Shanghai/Shenzhen
Lead Time :
Quantity(Sets) 1 - 10 11 - 20 >20
Est. Time(days) 7 15 To be negotiated
Product Description



Applicable Industry:
Mainly used to mark on various plastic buttons and electric devices, to mark code on CMOS

chip, color paper and food package. It can also be used in the scope with high requirements,

such as clock, jewelry, module, bitmap marking etc..

Introduction:

Fiber laser marking machine is the new generation marking system developed by our company

with advanced laser technique,it adopts fiber laser to output laser an achieves to marking

function after high speed scanning oscillating mirror system. It has higher photoelectric transfer efficiency. This machine adopts air cooling way and the whole machine is small, the out put beam is qualified, high reliability.





Fiber laser marking machine pictures

1. Imported high speed galvo scanner. (China brand optional)

2. Red dot positioning, working area: 110*110mm 200*200mm 300*300mm

Max/Raycus laser module 10w/20w/30w/50w(for choice)

Technical Parameters

Type: SH-F10/20/30/50
Laser power: 10w/20w/30w/50w(optional)
Laser wavelength: 1064nm
Marking area: 110*110mm/200*200mm/300*300mm
Laser source brand: Max/Raycus
Laser source lifetime: ≥100,000 hours
Marking line width: 0.01-0.1mm
Marking depth: <1mm depending on the material
Max marking speed: 7000mm/s
Repeatable accuracy: 0.001mm
Min letter: 0.15mm
Cooling system: Air cooling
Modulation frequence: 20kHz-200kHz
Working voltage: AC220V/110V
Unit power: <0.5kw
Software: Ezcad(in English)
Optional parts: Computer/lens/rotary device
Three type for choice: Table/Separately/Portable
Optional parts
More pictures of fiber laser marking machine
         Separately Type                                     Portable Type

Advantages:
1.Imported high speed galvo scanner. (China brand optional)
2.High precision with repetition as tiny as 0.2mm.
3.Fiber laser marking machine can make deep marking up to 1.0mm on stainless steel.
4.Fast marking speed with red dot pointer
5.Simple and convenient operation, easy to learn and handle.
6.Create intelligent designs.
7.Stable structure, little vibration during work.
8.Adopting Air Cooling way.
9.Run without maintenance.
10.No consumables: Fiber laser machine can be used for 8-10 years without any consumables.
11.Low power consumption: low cost, only 0.5kw per hour.
12.Perfect performance, 24 hours continuous working ability.
13.Long working life.

Samples
